Model 590 is the first handheld barcode scanner available to be assembled at the customer's side. Regardless of the wholesaler, reseller, distributor, or even the volume project users, this scanner allows customers to build up scanners the same as we do in our firm.
590 now offers four types of scanning engines from entry-level to high density, from 1D Laser to 2D Imager included Honeywell brand engines. All the functions of the scanner setting are the same unless the decoder and scan engine do not support it. this scanner adopts the easiest way to set up the program and deploy hundreds or thousands of scanners required.
590 is not the USB scanner but also supports VCOM CDC-ACM for Windows, Android & Linux OS. The extra-added value is built-in SD cards that support also connecting with the power bank as a data collecter.
590 Barcode scanner is the first scanner to adopt standard cable with Micro USB & USB A Type connectors. The customer can buy the cable in local computer stores to reduce the cost of international shipping freight.
we offer the customers the customized manual with their model name while the order quantities are qualified. The QTY required is very few.
Are you interested in this scanner? Buy one sample first to test now!
|
 |
| Model No |
590 TE |
590 TS |
590 TH |
590 LH |
| Image |
 |
 |
 |
 |
| Engine Type | 2D Entry Level
aidcti AE20 | 2D Standard
Honeywell N4680 | 2D High Density
aidcti AE21 | Laser 1D
Honeywell N4313 |
| Light Source | White LED illumination, Red LED dot aimer | Visible Laser Diode 650nm |
| Sensor | CMOS 640x480 Pixel | CMOS 1280x800 Pixel | 100 Scans/Sec. |
| Resolution | 4mil | 1D 3mil
2D 7mil | 1D 3mil
2D 5mil(DataMatrix PCS 90%) | 4mil |
| Scan Angle | Pitch: ±60°
Skew: ±55° | Pitch: ±50°
Skew: ±50° | Pitch: ±60°
Skew: ±70° | Default: 47°
Reduced: 35° |
| PCS | 20% | 20% | 25% | 20% |
Scan Range
5mil Code39 PCS 90% | 40mm ~ 190mm | 45mm ~ 180mm | 70mm ~ 300mm | 94mm ~ 201mm |
| Operating Mode | Trigger / Auto Sensing / Flash Scan / USB Drive Storage |
| Configuration Method | File update under Drag and Drop on USB Drive Storage Mode
Scan Config Barcode |
| Input voltage | 5V DC |
| Operating Power | 400mA typical values |
| Standby power | 90mA typical values |
| Illumination | 0 ~ 100,000 lux |
| ESD Protection | ±8KV indirect discharge |
| Operating Temperature | 0°C ~ 40°C |
| Storage Temperature | -40°C ~ 60°C |
| Humidity | 5% to 95% relative humidity, non-condensing |
| Shock Resistance | can withstand 1.8 meter of air drops |
| Housing Material | ABS |
| IP Rating | IP42 |
| Cable Type | 1.8M Length Standard Client USB Type A (Default) |
| Interface | USB / VCOM |
| 1D Barcode Symbologies | UPC-A, UPC-E, EAN-13, EAN-8, GS1-128, Code 39, Code 128, Interleaved 2 of 5, Codabar, Code93, MSI, Code 11, GS1-DataBar(RSS-14), UPC/EAN Add-On 2, UPC/EAN Add-On 5 |
| 2D Barcode Symbologies | PDF417, Data Matrix, QR Code, Aztec | - |
| Indicator | Buzzer
Green: Power On
Red: Decoding Success
Amber: Storage Mode |
| Dimensions | L170mm x W66mm x H85mm without cable |
| Weight | 120g without cable |
| Warranty | 18 Months limited warranty |
|
